IDT7024L20GB Original SRAM 4KX16 DUAL PORT Tray Memory Data Storage
Features
◆ True Dual-Ported memory cells which allow simultaneous reads of the same memory location
◆ High-speed access – Commercial: 15/17/20/25/35/55ns (max.) – Industrial: 20ns (max.) – Military: 20/25/35/55/70ns (max.)
◆ Low-power operation – IDT7024S Active: 750mW (typ.) Standby: 5mW (typ.) – IDT7024L Active: 750mW (typ.) Standby: 1mW (typ.)
◆ Separate upper-byte and lower-byte control for multiplexed bus compatibility
◆ IDT7024 easily expands data bus width to 32 bits or more using the Master/Slave select when cascading more than one device
◆ M/S = H for BUSY output flag on Master M/S = L for BUSY input on Slave
◆ Interrupt Flag
◆ On-chip port arbitration logic
◆ Full on-chip hardware support of semaphore signaling between ports
◆ Fully asynchronous operation from either port
◆ Battery backup operation—2V data retention
◆ TTL-compatible, single 5V (±10%) power supply
◆ Available in 84-pin PGA, Flatpack, PLCC, and 100-pin Thin Quad Flatpack
◆ Industrial temperature range (–40°C to +85°C) is available for selected speeds
◆ Green parts available, see ordering information
| SRAM |
| Shipping Restrictions: | This product may require additional documentation to export from the United States. |
| RoHS: | N |
| PGA-84 |
| Tray |
| Brand: | Original in stock |
| Height: | 3.68 mm |
| Length: | 27.94 mm |
| Product Type: | SRAM |
| Series: | 7024L20 |
| Factory Pack Quantity: | 3 |
| Subcategory: | Memory & Data Storage |
| Width: | 27.94 mm |
| Part # Aliases: | IDT7024L20GB 7024 |
